32ch 1080p HD NVR + 8 IP NETWORK CAMERAS w/POE TOTAL PACKAGE

Records 1080p REAL-TIME 30FPS per Channel
MOTORIZED 4X LENS!


8x 1080p IP ONVIF AUTO-ZOOM! 2.8-12mm,  WHITE Vandal IR Dome Cameras (100' IR)
1/2.8" Sony Exmor IMX322 Low Illumination Color High Definition Sensor
2.8-12mm Wide-Angle Auto-Zoom Lens, IR Cut Filter
Weatherproof Metal Armor domes with Excellent 30M Night Vision
Motion Detection alarm e-mail alert / record / index
Cloud Connection by software or http, with no port configuration!

(POE Switch Sold Separately) Power with YOUR POE Switch, or optional 12VDC

32ch 1080p Network Video Recorder (HDD sold separately, fits 2x SATA)

  Full HD 1080p







4x 2.8-12mm AUTO-ZOOM Lens, 36 IR LEDS = Infrared 100' Extreme NIGHT VISION
The 8 Infrared Domes AUTO-ZOOM through the NVR CMS software!

















Features
H.264 Pentaplex Network Video Recorder
Supports iphone, Android, Blackberry, Windows
*ONVIF Network Video Recorder -
Expandable to 32ch 1080p HD
32CH960P/32ch960p/16*720p  or 8*5MP / 16*4MP
HDMI Video Out

Records IP Cameras Locally, or remote
Port Configuration is simple
View All Onvif IP Cameras with one connection
(*not designed for analog cameras)



H.264, Pentaplex, ONVIF, High-Definition
Onvif IP Network Camera Support;
32*1080P, 32*960P, or 16*720p
or      8*5Megapixel / 16*4Megapixel

HDMI (1080P) Output + BNC + VGA
2x 6TB SATA Hard Drive (12TB Total)
(Hard Drives sold separately)
With XM cloud service, port configuration is unnecessary!
H.264 High Profile compression algorithm
Support various mobile monitoring( iPhone,Android,etc)
Support HD VGA and HDMI output simultaneously
Support multiple network services:
DHCP, PPPOE, FTP, DNS, DDNS, NTP, UPNP, EMAIL,
IP permissions,IP searches, Alarm Center, etc.)
And perfect support (WEB, Client, SDK)
Support IE, Chrome, Firefox, Safari browsers.
More than twenty languages
Perfect circuit protection, unique triple watchdog function
Simultaneous multi-channel real-time recording, playback.

CMS Software Disk + Manuals / Guides



OR 2nd App Goodeye





High Definition 1080p IP Network IR Cameras Weatherproof IP66 Metal Armor

8x 1080p IP ONVIF AUTO-ZOOM! 2.8-12mm,  WHITE Vandal Metal Dome Cameras
1/2.8" Sony Exmor Low Illumination Color High Definition Sensor
2.8-12mm Wide-Angle Auto-Zoom Lens, IR Cut Filter, 36LED IR  (100' IR).

FULL 1080P HIGH DEFINITION  Metal Armor IP66
8 Motorized 2MP IP Camera Domes Included
(expandable to 32 IP Cameras)


1/2.9" SONY Exmor™ Low Illumination Image Sensor 1920x1080






IR CUT FILTER,  Infrared Lasers = Extreme Night Vision





HD IP Network Cameras streaming video to PC/Smartphone; XMEYE.
PC Central Monitoring Software / complete Remote Management
3 PC Software Versions, VMS, CMS, CMS3 (MAC Version is also VMS)
(classic CMS version shown below)










GOODEYE Mobile APP, iOS, Android
Linux embedded H.264
High Profile Video Compression
Supports Maximum
2× 6TB SATA HDD [sold separately]
(7200RPM Seagate Barracuda Recommended)
CMS Central Monitoring Software
VGA, HDMI, PTZ , Mouse

NVR 3 in 1, Cloud technology,
HDMI output (1080P),  VGA, BNC
Intelligent Motion Detection Recording / Event Search
CPU: 1 * HI3535 Industrial Processor

Records IP Cameras Locally, or remote
Port Configuration is simple
View All Onvif IP Cameras with one connection

8*5MP
16*4MP
32*1080p
32*960p
16*720p

Intelligent, High Definition and Network Video Recorder
Multiple Redundant Recording Options
Cloud Video Survellance
Intelligent Video Analysis system
NVR: 3 in 1
Web, CMS, Meye
Supports 28 Languages

Web:
IE/Chrome/Firefox/Safari
Smart phone:
iphone/Android/Blackberry/Wndows/Nokia
CMS & Cloud Service:
Central Monitoring Software, Internet Cloud connection








We Sell Guaranteed Professional CCTV Products
*Customer Terms Warranty Information*
ONE YEAR LIMITED WARRANTY
against defects in materials and workmanship,
with the original buyer. Accessories carry a 30 day
(adapters, cables, baluns)warranty against defects
in materials and workmanship. We offer product exchange
and warranty with registration. See Return Policy
exclusions for details. By using this product
buyer agrees to product terms of use.




ONVIF IP Camera Recording
High Definition Recording for Onvif IP Cameras
HMDI 1920*1080, VGA Simultaneous Video Out



1.  H.264 High profile compression algorithm
2.  Realtime live display
3.  Pentaplex function: live recording, playback, backup & remote access;
4.  Support Dual-Streams for mobile monitoring flexible for network transmission.
5.  Multiple control methods: Network. USB mouse and front panel press button
6.  Smart video detection :motion detection, video blind, video loss
7.  Smart camera settings: privacy mask, camera lock ,color setting, and title display
8.  Easy backup methods :USB devices, remote network and client software backup
9.  Alarm triggering screen tips, buzzer, e-mail &FTP upload
10. Smart HDD Management: non-working HDD hibernation, HDD faulty alarm, Raid
11. Powerful network software: built-in web server, multi-NVR client Network access
for remote live viewing, recording playback, system status, event log, e-mail & ftp
12. DHCP / PPPOE / FTP / DNS / DDNS / NTP / Email alarm / IP rights MGMT
IP search / network alarm center functions, support web client, standalone client .
13. With the sound system for the protection circuit, unique triple watchdog function,
very low power consumption, to ensure equipment stability. Unique black box technology
monitors the whole run process of the equipment; greatly reducing maintenance costs.
14. Enable strong multi-way synchronization with max 4 channels playback,
realizing zero-delay between playback channels
15. Support IVS (intelligent video analysis system), like perimeter detection,
items care,  flow meter, abnormal video signal diagnosis
16. Supports iDVR cloud (www.xmeye.net), no router mapping required
17. Supports multiple high]definition network camera access,up to 5MP resolution;
18. Supports VGA, HDMI 1080P full HD output simultaneously;;
19. Supports multi]browser(IE,Chrome,Firefox,Safari)
20. Supports more than 20 kinds of languages
21. Supports P2P Cloud servicer www.xmeye.net / www.dvrcenter.net

NVR Specifications:








Model no.




VCSDVR-XM2D32







System




Main Processor




Industrial embedded
            microcontroller


Hisilicon CPU:
            Hi3535








Operating system




Embedded LINUX







System Resources




Simultaneous multi-channel real-time recording, playback,


Network operation, USB backup






Interface




Operation interface




16-bit true
            color graphical menu interface, support mouse operation








Screen display



            Preview screen 1/4/8/16/24/32






Video




Display Resolution




PAL(625TVL,50f/s);NTSC(525TVL,60f/s)








Video Compression




H.264(High Profile)






            Encode capability



            32CH 1080P Realtime (NVR mode)







Multi mode Digital


Channel config.



            32CH*1080P/16CH*1080P/8CH*1080P/32CH*960P/ 16CH*720P/16CH*4M/8CH*5M







Video input




NO







Motion detection




Zones:396(22*18)
            detection zones, Sensitivity(Multi-level sensitivity support)
            (Local channels only)






Audio




Audio compression




G.711A








Bidirectional
            Talk




YES (Intercom
            Function)






Record and playback




Record model




Manual>Alarm>Motion
            Detection>Continuous/Timing








Local playback



            4CH 1080P Realtime (NVR mode)







Record Search



            Time/calendar/event/channel search






Storage and
            backup




Space Occupation




Audio: 691.2M/day/channel


Video:1080P
            20~30G/day*ch, 720p 26G/day/ch








Recording Storage




Local HDD, network







Backup Mode



            Network backup,USB HDD,USB writer,SATA writer Interface






Port




Video input




no








Video output




1ch VGA,1ch
            HDMI







Audio input




Yes 1ch







Audio output




1ch RCA







Alarm input




no







Network port




RJ45 1000M Ethernet
            port







Network port




1× RJ45,
            10M  /  100M ,self-adaptive  Ethernet
            port







PTZ



            1*RS485,support 18 kinds of PTZ protocols







USB port




2pcs USB port







HDD



            2× 6TB SATA HDD [sold separately]







 WIFI




 3G,WIFI(extension
            via USB port)






Others




Onvif protocol




standard








Power supply




12V/4A







Dimension



            325(Length) x 255(Width) x 60 (Height)
